Transmille
Transmille Precision Resistance Standard, Model 3000RS
The 3000RS is a dedicated precision resistance standard.
The 3000RS is a modern precision resistance standard offering annual stabilities of better than 5ppm without the requirement for an oil bath, with temperature co-efficients as low as 0.1ppm/°C
Using ultra-high precision, 4-wire, hermetically sealed oil filled film resistors for values from 1 Ohm through to 100 kOhm, and oil filled precision wire-wound resistors for the 1 MOhm and 10 MOhm, the 3000RS is suitable for roles as either a working secondary set of resistors or a primary resistance reference.
Using the 3000RS with the 8500 low thermal scanner provides an automated solution for calibration of precision multimeters.
Schedule a Demo
Transmille
Transmille Precision Resistance Standard, Model 3000RS
Overview
3000RS Performance Highlights
| Range | Temp Coefficient (ppm/°C) | Stability / Year | Connection |
| 1 Ohm | 0.5 | 10 ppm | 4 Wire |
| 10 Ohm | 0.6 | 5 ppm | 4 Wire |
| 100 Ohm | 0.1 | 5 ppm | 4 Wire |
| 1K Ohm | 0.1 | 5 ppm | 4 Wire |
| 10K Ohm | 0.1 | 5 ppm | 4 Wire |
| 100K Ohm | 0.1 | 5 ppm | 4 Wire |
| 1M Ohm | 0.6 | 5 ppm | 2 Wire |
| 10M Ohm | 3 | 10 ppm | 2 Wire |
Features
- Dedicated Resistance Standard
- 8 Values from 1 Ohm to 10 MOhm
- Highest Precision Foil Resistors
- Extremely low Temperature Coefficients
- Lightweight and Portable
